RoHS XRF Analyzer
Working Principle
This benchtop X‑ray fluorescence (XRF) spectrometer leverages advanced X‑ray Fluorescence technology to provide highly accurate, non‑destructive testing performance. Its integrated X‑ray source delivers stable radiation to the test sample, exciting the emission of characteristic fluorescent photons from elements within both the coating and the substrate. These photons are effectively captured by a high‑sensitivity SDD or Si‑Pin detector, which converts optical signals into consistent electrical outputs. A 4096‑channel digital pulse processor then digitizes and precisely classifies these signals according to the unique energy signatures of individual elements. Finally, dedicated professional analytical software performs precise spectral deconvolution to accurately determine both coating thickness and elemental concentration, delivering measurement results that are dependable and highly repeatable.
Safety Protection
Multi-layer radiation protection design like automatic X-ray shutoff, radiation‑shielding structure
RoHS Directive Compliant Testing
It provides rapid, non-destructive screening of all RoHS-restricted hazardous substances (Pb, Cd, As, Hg, Cr, etc.)
Integrated Compact Design
10.1-inch touchscreen with integrated industrial computer, no external computer needed and less complex wiring.
Product Features
• Professional x-ray fluorescence instrument for rohs directive compliant;
• -10 °C to 50 °C (14 °F to 122 °F) temperature range ensures maximum uptime at full duty cycle;
• Ultra-low-noise electronics enable higher X-ray CPS for fast, accurate, and repeatable results;
• Optional wide element coverage from Mg - U or Ti - U;
• Intuitive English & Chinese user interface for quick device settings and software functions;
• Easy date export via a USB flash drive, Wireless LAN, or Bluetooth;
• Quad-core process speed up response and push the limits of performance;
• Anti-radiation structure module shield off stray X-rays;
X-ray Fluorescence Hardware & Software
• Stable 50 kV/1 mA X-ray source for consistent excitation;
• Proprietary ULS optical system reduces noise and improves detection sensitivity;
• High-speed 4096-channel digital pulse processor for accurate signal sorting;
• Optional high-resolution SDD detector for enhanced trace-element performance;
• Patent RoHs analysis software automates the identification, precise quantification and standardized reporting;
• Program-controlled 6 filter wheels minimize background noise and maximize detection sensitivity.
OEM & ODM Service
• Multi-language touchscreen interface customization;
• Tailored user manuals and technical documentation;
• Brand logo imprint on the instrument and packaging;
• Custom test modes and application data base;
• Exclusive exterior and packaging design.
Contact our engineers right now and custom if you need exclusive OEM and ODM service.
Applications
The instrumentation of x ray fluorescence could be applied to following conditions (but not limited to) for XRF rohs testing:
• Toys, costume jewelry, small trinkets, art supplies (crayons, chalk), plastic products, lunch containers, and backpacks;
• Garments, zippers, buttons, appliqués, rhinestones, decorative trims, handbags, and wallets;
• Sporting goods, swing sets, picnic tables, wooden decks, and perimeter fences;
• Ornamental food containers, colored ceramic pieces, and silver-plated hollowware;
• Candy wrappers, infant food products, dietary supplements, and general foodstuffs;
• Drapery, upholstered furnishings, and area rugs;
• Vehicles, car seats, leather upholstery, fiber materials, interior trims, control knobs, wheels, and floor mats;
